Soil Belt Conveyor With Large Conveying Capacity For Loading And
Unloading
Description & Application
The Soil belt conveyor with large conveying capacity for loading
and unloading is a kind of continuous mechanical handing equipment
with high efficiency, good safety and good mobility. Mainly used
for short-distance transport, handing of bulk material and the
product one-piece weight less 100kg on loading and unloading
stations which are often changed, such as the port, terminal,
station, coal yard, warehouse, building site, sand quarry, farm and
so on. It can be divided into lift and not lift type, the running
of belt is driven by electric-roller, and the whole lifting and
running are non-motorized.
Specification / Technical Parameter:
| Width(mm) | Length(m)/Power(kw) | Speed(m/s) | Capacity(t/h) |
| 400 | ≤12/2.2 | 12~20 /2.2~4 | 20~25/3.5~7.5 | 1.25~2.0 | 30~60 |
| 500 | ≤12/3 | 12~20/3~5.5 | 20~30/5.5~7.5 | 1.25~2.0 | 40~80 |
| 650 | ≤12/4 | 12~20/4~5.5 | 20~30/5.5~11 | 1.25~2.0 | 80~120 |
| 800 | ≤10/4 | 10~15/4~5.5 | 15~30/5.5~15 | 1.25~2.0 | 120~200 |
| 1000 | ≤10/5.5 | 10~20/5.5~11 | 20~40/11~22 | 1.25~2.0 | 200~320 |
| 1200 | ≤10/7.5 | 10~20/7.5~15 | 20~40/15~30 | 1.25~2.0 | 290~480 |
Advantages:
The Soil belt conveyor with large conveying capacity for loading
and unloading can be widely applied to the bulk material and
packaged bag items in industries like coal, metallurgy, chemical
engineering, hydroelectricity, traffic, building material and so
on. Its performance and main technical parameters are equal to
Germany Flender and Thyssen company's products.It can be used for
not only horizontal conveying, but also inclining conveying in
which there is inclination and uneven segment. With simple
structure, high precision and long lifetime, it is used
conveniently and universally.
Note:The conveying amount in the table is formulated on the
condition that the material’s specific weight r=1 t/m3 , the
conveyer’s inclining angle is 0~7°, and the angle of repose is 30°
Redesign for customer’s special demand is available.
If you want to order our products, please answer to these questions
carefully. So that we can better to help you to chose the matching
model
1. What's the material will you transported, bag material or bulk
material
2. If bag material, please tell us the weight of every bag, If bulk
material, please tell us the capacity?
3. What's the length and the lifting height do you required?
